Hino 500 Series

1322 4×4 FC

The Hino 500 Series 1322 4×4 FC is a heavy-duty all-wheel-drive truck engineered for demanding off-road and commercial applications. Powered by a 7.7L turbo-intercooled diesel engine producing 152 kW and 603 Nm of torque, it features a 6-speed manual transmission with a dual-range transfer case, a Gross Vehicle Mass (GVM) of 13,000 kg, and a 4,650 mm wheelbase. Its permanent 4×4 capability and robust chassis make it ideal for construction, mining, forestry, emergency services, and specialist off-road operations.

Engine

  • Manufacturer: HINO
  • Model: J08E-YB
  • 4-Stroke Compression Ignition: Yes
  • Aspiration: Turbo-Intercooled
  • Bore × Stroke: 112 × 130 mm
  • Capacity: 7,684 cc
  • Compression Ratio: 18:1
  • Configuration: Six Cylinder In-Line
  • Engine Oil Cooler: Yes
  • Euro Emission Status: Euro 3
  • Firing Order: 1-4-2-6-3-5
  • Governor (All Speed / RLD): Yes
  • Governor (Electric): Yes
  • Injector Pump: Common Rail
  • Maximum Engine Speed: 2,900 rpm
  • Number of Cylinders: 6
  • Maximum Power (EEC/ISO NET): 152 kW @ 2,500 rpm
  • Maximum Torque: 603 Nm @ 1,500 rpm
  • Type of Cylinders (Liners): Dry Liners
  • Valve Configuration: OHC

Transmission

  • Type: Full Synchromesh (2nd–6th Gears)
  • Gear Ratio (1st – Top Gear): 6.515 – 1.000
  • Gearshift Operation: Cable
  • Manufacturer: HINO
  • Model: LX06S
  • Number of Forward Gears: 6
  • PTO & Control: Not Standard
  • Reverse Ratio: 6.06
  • Transfer Box Ratio: 2.224 Low / 1.000 High
