Hino 500 Series

1627 TIP

The Hino 500 Series 1627 TIP is a heavy-duty tipper truck engineered for construction, mining, and demanding earthmoving applications. Powered by a 7.7L turbo-intercooled diesel engine producing 191 kW and 794 Nm of torque, it features a 6-speed manual transmission, a Gross Vehicle Mass (GVM) of 16,000 kg, and a 3,730 mm wheelbase. Its compact wheelbase and durable chassis provide excellent maneuverability while delivering outstanding payload capacity for tipper operations.

Engine

  • Model: J08E-WH
  • 4-Stroke Compression Ignition: Yes
  • Aspiration: Turbo-Intercooled
  • Bore × Stroke: 112 × 130 mm
  • Capacity: 7,684 cc
  • Compression Ratio: 18:1
  • Configuration: Six Cylinder In-Line
  • Engine Oil Cooler: Yes
  • Euro Emission Status: Euro 3
  • Firing Order: 1-4-2-6-3-5
  • Governor (All Speed / RLD): Yes
  • Governor (Electric): Yes
  • Injector Pump: Common Rail
  • Maximum Engine Speed: 2,750 rpm
  • Number of Cylinders: 6
  • Maximum Power (EEC/ISO NET): 191 kW @ 2,500 rpm
  • Maximum Torque: 794 Nm @ 1,500 rpm
  • Valve Configuration: OHC

Transmission

  • Type: Full Synchromesh (2nd–6th Gears)
  • Gear Ratio (1st – Top Gear): 6.515 – 0.702
  • Gearshift Operation: Cable / Air Assist
  • Manufacturer & Model: HINO MX06
  • Number of Forward Gears: 6
  • PTO & Control: Not Standard
  • Reverse Ratio: 6.991
  • Transfer Box Ratio: N/A
